HLG 750 Diablo commercial Indoor Horticulture LED grow light with integrated reflectors improves photon delivery to the canopy and has an improved full spectrum with Samsung Full Spectrum White and Deep Red LED’s. The 750 Diablo has an efficacy of 2.88 µmol/joule and uses 4 Advanced Design Diablo Quantum Boards® with an even light spread.

Top Features

2.88 PPF/W High Efficiency at 714 watts

2056 PPF High Output to replace even 1000W DE

Integrated reflectors for increased photon delivery

Full Spectrum White and Deep Red

Reliable passive-cooled design

Better canopy light penetration with diffused light

0 to 714 Watts Dimmable design

Auto sensing power supply works on both 120VAC, 240VAC, and 277VAC

5 Year Warranty

 Specifications:

LED Full Spectrum White & Deep Red

PPF 2056

Efficacy 3.062.88 μmol/joule

Voltage Range 120VAC - 277VAC : 50/60 Hz

Power 0-714 Watts

Flowering Footprint 5' x 5'; 7’ x 7’ for Veg

Recommended mounting height above canopy 24” Flowering; 42” for Veg

Thermal Management Passive-Cooled Design

Max Ambient Temperature 40C (104F)

Dimmable Options 0-10V Dimmable, RJ12, Wireless

Dimensions 37.5" x 27.125" x 3.75"

Weight 20.25 lbs

Warranty 5 Years*

HLG 750 Diablo Manual
Independent Efficiency Lab Report
GrowFlux Information Booklet

*An Access Point (sold separately) is required if you choose the GrowFlux wireless dimming option.
